พิมพ์หน้า
262 ในสต็อก
อยากได้เพิ่มใช่ไหม
262 จัดส่งใน 3-4 วันทำการ(อังกฤษ สต็อก)
| จำนวน | ราคา (ราคาสินค้าไม่รวม vat) |
|---|---|
| 1+ | THB762.770 |
| 10+ | THB744.260 |
| 50+ | THB726.900 |
| 100+ | THB709.300 |
| 250+ | THB692.610 |
ราคาสำหรับสินค้า:Each
ขั้นต่ำ: 1
หลายรายการ: 1
THB762.77
บันทึกของรายการ
เพิ่มไปยังใบยืนยันคำสั่งซื้อ ใบแจ้งหนี้ และใบจัดส่งสินค้าสำหรับคำสั่งซื้อนี้เท่านั้น
จำนวนนี้จะถูกเพิ่มลงในใบยืนยันคำสั่งซื้อ ใบแจ้งหนี้ ใบจัดส่งสินค้า อีเมลยืนยันทางเว็บ และฉลากผลิตภัณฑ์
ข้อมูลผลิตภัณฑ์
ผู้ผลิตEAO
หมายเลขชิ้นส่วนของผู้ผลิต19-471.035
รหัสสินค้า150585
Product Range19 Series
เอกสารข้อมูลทางเทคนิค
Product Range19 Series
Panel Cutout Diameter8mm
Contact ConfigurationSPST-NO
Switch OperationOff-On
Pushbutton Actuator StyleRound
Actuator / Cap Colour-
Contact Current AC Max100mA
Contact Voltage VAC50V
Contact Current DC Max-
Contact Voltage VDC-
IP RatingIP40
Switch MountingPanel Mount
Switch TerminalsQuick Connect, Solder
Illumination Colour-
Panel Cutout (H x W)-
ภาพรวมของผลิตภัณฑ์
The 19-471.035 is a single-pole single-throw (SPST) illuminated Pushbutton Switch with a polyphenylene oxide actuator, gold contacts and solder terminal. The 19 series switch equipped with low level switching elements, maintain function and 1NO contact. The universal terminals of the low-level switching elements permit them to be mounted on printed circuit boards (PCB).
- Polycarbonate flat lens
- Raised design
การใช้งาน
Imaging, Video & Vision, Audio
ข้อมูลจำเพาะทางเทคนิค
Product Range
19 Series
Contact Configuration
SPST-NO
Pushbutton Actuator Style
Round
Contact Current AC Max
100mA
Contact Current DC Max
-
IP Rating
IP40
Switch Terminals
Quick Connect, Solder
Panel Cutout (H x W)
-
Panel Cutout Diameter
8mm
Switch Operation
Off-On
Actuator / Cap Colour
-
Contact Voltage VAC
50V
Contact Voltage VDC
-
Switch Mounting
Panel Mount
Illumination Colour
-
เอกสารทางเทคนิค (1)
ผลิตภัณฑ์ที่เกี่ยวข้อง
พบผลิตภัณฑ์จำนวน4
กฎหมายและปัจจัยแวดล้อม
ประเทศต้นกำเนิด:
ประเทศสุดท้ายที่ดำเนินกระบวนการผลิตที่สำคัญประเทศต้นกำเนิด:Switzerland
ประเทศสุดท้ายที่ดำเนินกระบวนการผลิตที่สำคัญ
ประเทศสุดท้ายที่ดำเนินกระบวนการผลิตที่สำคัญประเทศต้นกำเนิด:Switzerland
ประเทศสุดท้ายที่ดำเนินกระบวนการผลิตที่สำคัญ
หมายเลขพิกัดอัตราภาษี:85365011
US ECCN:EAR99
EU ECCN:NLR
เป็นไปตามข้อกำหนด RoHS:ใช่
RoHS
การใช้สารพาทาเลตตามระเบียบ RoHS:ใช่
RoHS
ดาวน์โหลดหนังสือรับรองมาตรฐานของผลิตภัณฑ์
หนังสือรับรองมาตรฐานของผลิตภัณฑ์
น้ำหนัก (กก.):.00257
